AIDA Imaging UHD-X3L 4K HDMI POV Camera
Description
Description
AIDA Imaging UHD-X3L 4K HDMI POV Camera
Drive your visual inspirations with clarity. The UHD-X3L with its built-in 4K 3X optical zoom lens simplifies the creation of video content that requires Ultra-HD quality and remote versatility. Application ranging from sports to telemedicine.
Technical Specifications
Video
Image Sensor
1/2.5 Progressive CMOS
Sensor Size
Diagonal 7.20mm
Effective Pixels
Horizontal: 3840, Vertical: 2202
Pixel Size
1.62 m (H) x 1.62 m (V)
Resolution
2160p: 3840 x 2160 1080p / 1080i: 1920 x 1080 720p: 1280 x 720
Resolution | Rate
4K2160p: 30 / 29.97 / 25 / 24 1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 1080i : 60 / 59.94 / 50 720p: 60 / 59.94 / 50
Output
HDMI 1.4
Color Space
4:2:2 (YCbCr) 10bit
Function
White Balance
AWB / AE / AF
Exposure
Full Auto, Bright, Shutter Priority, Iris Priority, Manual
Other
WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction, Digital Slow Shutter, Black Level Compensation, Flicker Detection
Lens
3X Optical Zoom Lens, 3.85mm/78 (Wide) ~ 13.4mm/25 (Tele)
Physical
Camera Control
RS-485 VISCA, OSD Button
Operation Temp
32 F - 104 F
Dimension
48mm x 48mm x 83.09mm / 1.89 x 1.89 x 3.27
Weight
140g / 0.30lbs
Power
12 VDC (+9 - +15VDC)
