BirdDog BDWPOUT Wallplate Dual Output
NDI Wallplates are the answer to elegant and permanent NDI installations. With two models to choose from, Dual Input or Dual Output, they have been designed to make boardroom setups a breeze. Install the Dual Output in the wall to drive content to the TV screens and install the Dual Input into the meeting table to take inputs from laptops and other devices using EDID. Wallplates are all built upon BirdDog’s custom NDI chip and can be completely automated via the programmable RESTful API, and also feature PoE for single Ethernet cable functionality, Mic Input, Speaker output, interchangeable faceplates, soft glow status indicators, and a easy to use web management console to change settings. Wallplate Output features two independent outputs and is designed for driving content to screens. Output the video conferencing group to one screen and output the presentation or laptop screen share to another screen to make for super engaging meetings. There is also a speaker output for connecting to an audio system. Use the RESTful API to automate the workflow. Wallplate Input has complete EDID to automatically convert your laptop’s HDMI input into a supported resolution to send to Wallplate Output. This makes for a seamless user experience in boardrooms and anywhere you need to get your laptop onto a TV.
Key Features
- NDI Wallplates for Building the Ultimate AV Experience
- Wallplate Output
- HDMI Auto Detection with EDID
- RESTful API. DIY automation
- Flush Mounted
- One Cable for PoE, Video, Audio
- Extreme Speed. It’s all about the silicon
- Interchangeable Faceplates. Soft Glow Indicators
- Web Management Console
- Distribute NDI content everywhere
Technical Specifications
Video Format
(HD) 1080p 23.98, 25, 29.97, 50, 59.94
(HD) 1080i 50, 59.94
(HD) 720p 50, 59.94
Video Output
2 x HDMI Standard Type A connector HDMI v1.4a, RGB or YCbCr
Audio digital
2-Channel, 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio analog
3.5mm microphone input
3.5mm stereo output
Video Codec support
Realtime, ultra-low latency, full-bitrate NDI (i-frame)
Soft glow Indicators
User definable status indicators to show active/non-active connections.
Network Interface
10/100/1000 Ethernet (RJ-45) with PoE (Power over Ethernet) Embedded web configuration panel for control and firmware updates
Power
Power over Ethernet (PoE) 802.3af/at
