Bosch LB20-PC30-5L 5 Inch 70/100V Quick Install IP54 Speaker, White

Bosch LB20-PC30-5L 5 Inch 70/100V Quick Install IP54 Speaker, White

The LB20-PC30-5 from Bosch is a high-performance , two-way, full-range, 5.25" (133 mm) surface mount speaker with excellent wide, uniform coverage, and outstanding performance. It is designed for background and foreground music, paging, and sound reinforcement, and it's ideal for a wide variety of indoor and outdoor applications, such as restaurants, bars, patios, retail, fitness clubs, hospitality, theme parks, leisure venues, and others.

Key Features

• Innovative mount system is included for quick, simple, and reliable installations
• Carefully engineered for outdoor environments (IP54), without compromising performance
• Long throw 5.25" (133 mm) woofer housed in a fire rated ABS plastic enclosure for extended LF performance down to 60 Hz
• 75 W power handling provides for 109 dB maximum SPL (115 dB peak)

Technical Specifications

Frequency response (-3 dB)
85 Hz - 20 kHz1
Frequency response (-10 dB)
60 Hz - 20 kHz1
Sensitivity
90 dB2
Max SPL (calculated)
109 dB (115 dB Peak)
Coverage angle
Horizontal 90, Vertical 90
Power handling
75 W (300 W Peak) Continuous Pink Noise (100 hours)
Low Z
Yes
Nominal impedance
8
Minimum impedance
6
Recommended High-Pass
60 Hz (24 dB/octave)
Input transformer (70 V/100 V)
30 W
Transformer taps
70 V: 3.7 W, 7.5 W, 15 W, 30 W, 8 100 V: 7.5 W, 15 W, 30 W, 8
LF transducer
5.25 inch (133 mm)
HF transducer
0.75 inch (20 mm)
Connectors
Captive screws on wall bracket.Removable locking 4-pin connector (Euroblock) - (2) for connection to additional speakers in a distributed line.Max. wire size 12AWG (2.5 mm)
Environmental
IP54 (per IEC-60529)
Color
Black (RAL 9004) or white (RAL 9003)
Dimensions (H x W x D)
255 mm x 180 mm x 154 mm (10.0 in x 7.1 in x 6.0 in)3
Net weight
3.2 kg (7.0 lb)3
Shipping weight (pair)
7.9 kg (17.5 lb)
Included hardware
Mounting bracket and 5-mm Allen wrench
Packaged quantity
2
