BZBGEAR BG-8K-42MA 4×2 8K UHD HDMI 2.1 Matrix Switcher with Audio De-embedder

BZBGEAR BG-8K-42MA 4×2 8K UHD HDMI 2.1 Matrix Switcher with Audio De-embedder

The BG-8K-42MA 8K HDMI matrix switch is the perfect solution for users who need to share up to four HDMI sources with up to two displays. With its user-friendly interface and advanced features, this matrix switch allows you to effortlessly switch between multiple sources, or display a single source on two displays with just the press of a button.

This high-performance switch is designed for both professional and recreational use all while delivering exceptional picture and audio quality thanks to its support for 8K resolutions and a range of high-quality audio formats. Whether you're working on a demanding post-production project, need a reliable tool for sharing content in a business setting, or an easier way to manage several gaming consoles, the BG-8K-42MA has you covered.

Connectivity and Quality

The BG-8K-42MA matrix revolutionizes multimedia with its support for 8K resolutions at various frame rates and chroma subsamplings, including 8K@60Hz 4:2:0, 8K@30Hz 4:4:4, and 4K@120Hz 4:4:4 with HDR. Its 48 Gbps uncompressed bandwidth ensures pristine HDMI signal transmission, maintaining original quality throughout. This matrix excels in content protection too, boasting HDCP 2.3 compliant HDMI ports. Notably, its auto downscaling feature guarantees compatibility with older displays, adapting output effortlessly.

Beyond visuals, the BG-8K-42MA offers comprehensive audio support, including digital S/PDIF and balanced audio output formats. This integration of cutting-edge resolutions, signal integrity, content security, legacy compatibility, and rich audio capabilities transforms multimedia experiences into captivating symphonies of sight and sound, setting an unmatched standard for excellence.

Control

The BG-8K-42MA offers multiple control methods including front panel controls, IR remote control, RS-232, or TCP/IP (Web GUI). The included IR receiver allows the unit to be controlled with the included remote while located out of sight for a clean installation.

In addition to a full-featured web interface, the BG-8K-42MA includes control software that can be operated via the RS-232 connection. These interfaces provide users with the ability to adjust advanced features such as EDID management, mapping, and network settings.

Play Games at 4K@120Hz!

For gamers, the ability to display high-resolution graphics at high frame rates is crucial for a smooth and immersive gaming experience. With support for 4K resolution at 120Hz, the BG-8K-42MA can help ensure that your games are displayed with the highest level of detail and fluidity. This is particularly important for fast-paced games where a high frame rate can make a significant difference in your ability to react to in-game events.

Whether you're playing competitively or just looking for the most realistic and engaging gaming experience possible, the 8K HDMI 4x2 matrix switcher's support for 4K at 120Hz can help you get the most out of your favorite games.

Key Features

• Supports 8K and 4K120 Video resolution up to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4 10bit, 4K@120Hz 4:4:4 10bit
• Easy Control Options IR remote control and front panel button switching
• HDMI audio formats LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
• Automatic downscaling 8K->4K, 8K/4K->2K downscaling
• High quality and secure content HDMI 2.1 and HDCP 2.3 compliant
• Compact design For easy and flexible installations
• Supports 40Gbps of video bandwidth
• VRR, FVA, ALLM
• HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through
• INPUT 1 and OUTPUT 1 ports support ARC/eARC
• Allows HD audio up to Dolby Atmos/DTS:X over TrueHD from ANY external HDMI source to a supported eARC/ARC sound system
• Audio de-embedding (output through the optical and analog port)
• Built-in EDID DIP switches support advanced EDID management
• Built-in Equalizer, Retiming, and Driver

What's in the Box

• 1 x 8K HDMI 4x2 Matrix Switcher
• 1 x IR Remote
• 1 x 5V/2A Multinational Power Supply
• 1 x User Manual
