MuxLab 500774-RX-MM HDMI 2.0/ST2110 Over IP Uncompressed Gateway Converter Receiver, MM

MuxLab 500774-RX-MM HDMI 2.0/ST2110 Over IP Uncompressed Gateway Converter Receiver, MM

The HDMI 2.0/ST2110 over IP Uncompressed Gateway Converter allows lower cost HDMI 2.0 equipment to utilized in a broadcast environment and extended up to 1300ft (400m) via duplex multimode OM4 fiber with LC connectors, at up to 4K resolution @ 60Hz uncompressed, in a point-to-point configuration. Point-to-multipoint and multipoint-to-multipoint configurations are also possible by connecting several units to a 10G Ethernet network. The unit provides a 1G Ethernet Switch port to connect additional network devices, and an RS232 port for remote control of end devices.

Key Features

• Supports Uncompressed HDMI video up to 4K @ 60Hz and SMPTE ST-2110
• Extend HDMI over an IP network at up to 1300ft (400m) over duplex OM4 fiber
• Supports 100’s of Transmitters & Receivers depending on network bandwidth
• Supports point-to-point, point-to-multipoint and multipoint-to-multipoint applications
• Supports two 10G Ethernet ports for communications and a 1G Switch port for additional network devices
• Supports audio insert (TX) & audio extract (RX)
• Supports RS232 for remote control of end devices
• Managed via its Web interface and RestAPI
