RCF L 2406 | 3 Way Passive Column Array Speaker White
Description
Description
RCF L 2406 3 Way Passive Column Array Speaker White
The L 2406 is a compact, full-range 3-way column loudspeaker with a high level of intelligibility and controlled vertical directivity. Thanks to a very natural and intelligible reproduction of the voice and an excellent quality of music reproduction, it is the ideal choice for various fixed applications in which the difficult acoustic environment or architectural constraints require the control of vertical acoustic dispersion. It features six 5 "mid-woofers and four 1" dome tweeters. Its construction with central tweeters mounted in front of the two woofers allows a uniform dispersion of the sound that minimizes lobing and allows a very compact design. The two mid-woofer units behind the tweeters are controlled differently by the four external low frequency transducers, thus providing cardioid operation and improving directivity.
Key Features
- High efficiency
- Six 5 "woofers and four 1" tweeters
- Controlled dispersion
- Special filter for greater speech intelligibility
- LICC (Low Impedance Compensated Crossover)
- Protection circuit for tweeters
- Accessory for integrated wall mounting
- 200 W to 8 Ohms
Technical Specifications
Acoustic specifications
FREQUENCY RESPONSE (-10 DB)
100 Hz ÷ 20000 Hz
SPL MAX. AT 1 M (DB)
126 dB
HORIZONTAL COVERAGE ANGLE (°)
150th
VERTICAL COVERAGE ANGLE (°)
30 °
DIRECTIONALITY INDEX Q:
9
SYSTEM SENSITIVITY (DB)
97 dB
Dimensions
HEIGHT
826 mm / 32.52 inches
OVERALL WIDTH
135 mm / 5.31 inches
DEPTH
140 mm / 5.51 inches
WEIGHT
12.8 kg / 28.22 lbs
