TOA Electronics BA-235 35W Power Amplifier
Description
Description
The TOA Electronics BA-235 35W Power Amplifier is specifically designed for background music and general announcements, making it a perfect choice for various establishments such as bars, retail stores, and banquet rooms. It offers a power output of 35 W, ensuring a clear and powerful sound experience.
To enhance its functionality, the BA-235 can be used in conjunction with the optional mixer amplifiers BG-220 (20 W) or BG-235 (35 W). This allows for a 2-channel broadcast, enabling multiple audio sources to be played simultaneously. With this setup, you can easily create a dynamic and immersive audio environment for your venue.
The TOA BA Series power amplifiers are the ultimate solution for installations in a wide range of settings including restaurants, retail stores, lounges, classrooms, and meeting rooms. These amplifiers are built with TOA's cutting-edge technology, guaranteeing exceptional performance and audio quality. They offer a wide frequency response, ensuring that every detail of the audio is reproduced accurately. Additionally, the BA Series amplifiers have low noise and distortion levels, providing a clean and clear sound output. With stable output regulation, you can rely on these amplifiers to consistently deliver high-quality audio.
Technical Specifications
Power Source
120 V AC, 60 Hz
Rated Output
35 W
Power Consumption
90 W (rated output), 52 W (based on cULus standards)
Frequency Response
50 Hz - 20 kHz
Total Harmonic Distortion
0.5 % or less, at 1 kHz, rated output
Input
Line In: 0 dB*/+4 dB* (selectable), 10 kΩ, unbalanced,
removable terminal block or RCA jack
Output
Speaker: 4 Ω, 25 V (18 Ω) and 70 V (140 Ω),
balanced, removable terminal block
Bridge: parallel in Line in, removable terminal block
Output Regulation
2 dB or less, no load to full load (1 kHz)
S/N Ratio
80 dB or more
(Band Pass: 20 Hz - 20 kHz, Tone Controls: Centered)
Tone Control
Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz
Control
Master gain control, Bass tone control, Treble tone control,
Input Level selector switch, Remote Volume control, Power ON/OFF switch
Indicator
Power LED, Signal LED, Peak LED
Operating temperature
0 ℃ to +35 ℃ (32 ゜F to 95 ゜F)
Operating Humidity
35 % to 80 %RH (no condensation)
Finish
Panel: ABS resin, black
Case: Steel plate, black, paint
Dimensions
210 (W) × 94.3 (H) × 265 (D) mm (8.27" × 3.71" ×10.43")
Weight
4 kg (8.82 lb)
Accessory
Volume control cover: YA-920 ……1
Removable teminal plug (2 pins) ……3
Removable teminal plug (4 pins) ……1
Option
Rack mounting bracket: MB-25B-BK, MB-25B-J
