tvONE C2-8110 6 x 2 CORIO2 Universal I/O Seamless Switcher
Description
Description
tvONE C2-8110 6 x 2 CORIO2 Universal I/O Seamless Switcher
C2-8000 Series multi-format products offer the ultimate flexibility for switching and scaling a wide range of analog and digital video signals. CORIO2 or C2- based products provide the benchmark for video image conversion products, coming nearer the ideal of "Anything In - Anything Out" than any other conversion products on the market. Some of the functions include: SDTV/HDTV Conversion, Digital/Analog Conversion, Aspect Ratio Conversion, Up/Down-Conversion, Video Scaling, Multi-Format Seamless Switching, Worldwide Standards Conversion, Chroma/Lumakeying, Picture-in-Picture Windowing, TBC/Frame Synchronization, and much more.
Key Features
- 1RU size
- High quality seamless switching
- Up-Down-Cross Conversion
- DVI-U inputs (HDMI/CV/YC/RGB/YPbPr): up to 12
- SDI inputs: up to 2 SD/HD/3G-SDI + re-clocked out
- DVI-U outputs: 2 (HDMI/CV/YC/RGB/YPbPr)
- SDI outputs: up to 2 (SD/HD/3G)
- Genlock inputs: 1x Tri/Bi with loop-through
- Analog: PC to 2048x2048, HDTV to 1080p/60
- DVI: PC to 1920x1200, HDTV to 1080p/60
- Supports: NTSC, PAL, PAL-M, PAL-N, SECAM
- HDMI-compatible input & output with HDCP
- Motion Compensation & 3:2 Pull-down
- Diagonal Interpolation
- Noise Reduction for PAL, NTSC and 1080i inputs
- Automatic Incoming Resolution Detection
- AutoSet - Automatic picture sizing of PC inputs
- 4:4:4 Full bandwidth sampling
- Variable Image Zoom to 10X and Shrink to 10%
- Chroma and Luma keying
- Fade, Wipe, Push, Cut transitions
- Video signal parameter adjustments
- Audio de-embed / embed for SDI and DVI
- Closed-caption de-embed / embed for CV / SDI
- Integral Audio Routing
- User-defined Logo insertion
- Still image store
- Borders with variable size and colour
- IP Interface
- RS-232/422/485 interface
Technical Specifications
Video Inputs
Television Standards
NTSC, PAL, PAL-M/N, SECAM
Composite Video
Up to 6x via DVI-U
YC (S-Video)
Up to 6x via DVI-U
YUV /YPbPr
Up to 6x via DVI-U
Computer Inputs
Digital DVI (HDMI & HDCP compatible)
Up to 6x via DVI-U
Analog
Up to 6x via DVI-U
Analog Format
RGBHV, RGBS, RGsB, YPbPr
Analog Signals
PC to 2048x2048, HD to 1080p60
DVI Signals
PC to 1920x1200, HD to 1080p60
Mechanical
Size (H x W x D)
1.73” x 17.0” x 13.1” (44 x 431 x 334mm)
Weight (Net)
Approx. 5Kg
