tvONE C2-8130 12 x 2 CORIO2 Universal I/O Seamless Switcher
Description
Description
tvONE C2-8130 12 x 2 CORIO2 Universal I/O Seamless Switcher
These multi-format products offer the ultimate flexibility for switching analog and digital video signals and conversion between video and computer formats and resolutions. They are based on our exclusive CORIO 2 conversion technology and are capable of dealing with virtually any type of analog or digital video signal. CORIO2 based products provide the benchmark for video image conversion products, coming nearer the ideal of "Anything In - Anything Out" than any other conversion products on the market. Some of the functions include: SDTV/HDTV Conversion, Digital/Analog Conversion, Aspect Ratio Conversion, Up/Down-Conversion, Video Scaling, Multi-Format Seamless Switching, Worldwide Standards Conversion, Chroma/Lumakeying, Picture-in-Picture Windowing, TBC/Frame Synchronization, and much more.
Key Features
- 1RU size
- High quality seamless switching
- Up-Down-Cross Conversion
- DVI-U inputs (HDMI/CV/YC/RGB/YPbPr): up to 12
- SDI inputs: up to 2 SD/HD/3G-SDI + re-clocked out
- DVI-U outputs: 2 (HDMI/CV/YC/RGB/YPbPr)
- SDI outputs: up to 2 (SD/HD/3G)
- Genlock inputs: 1x Tri/Bi with loop-through
- Analog: PC to 2048x2048, HDTV to 1080p/60
- DVI: PC to 1920x1200, HDTV to 1080p/60
- Supports: NTSC, PAL, PAL-M, PAL-N, SECAM
- HDMI-compatible input & output with HDCP
- Motion Compensation & 3:2 Pull-down
- Diagonal Interpolation
- Noise Reduction for PAL, NTSC and 1080i inputs
- Automatic Incoming Resolution Detection
- AutoSet - Automatic picture sizing of PC inputs
- 4:4:4 Full bandwidth sampling
- Variable Image Zoom to 10X and Shrink to 10%
- Chroma and Luma keying
- Fade, Wipe, Push, Cut transitions
- Video signal parameter adjustments
- Audio de-embed / embed for SDI and DVI
- Closed-caption de-embed / embed for CV / SDI
- Integral Audio Routing
- User-defined Logo insertion
- Still image store
- Borders with variable size and colour
- IP Interface
- RS-232/422/485 interface
Technical Specifications
Video Inputs
Television Standards
NTSC, PAL, PAL-M/N, SECAM
Composite Video
Up to 12x via DVI-U
YC (S-Video)
Up to 12x via DVI-U
YUV /YPbPr
Up to 12x via DVI-U
Computer Inputs
Digital DVI (HDMI & HDCP compatible)
Up to 12x via DVI-U
Analog
Up to 12x via DVI-U
Analog Format
RGBHV, RGBS, RGsB, YPbPr
Analog Signals
PC to 2048x2048, HD to 1080p60
DVI Signals
PC to 1920x1200, HD to 1080p60
Mechanical
Size (H x W x D)
1.73” x 17.0” x 13.1” (44 x 431 x 334mm)
Weight (Net)
Approx. 5Kg
