BASSBOSS KRAKEN-MK3 10000W Quad 21-Inch Hybrid Powered Subwoofer

Kraken-MK3: The Ultimate Bass Experience
Experience the most powerful bass output from the most compact subwoofer – Kraken-MK3. This subwoofer is engineered to dominate large-scale festival touring systems, high-intensity nightclubs, art cars/festival floats, and the insatiable hunger of bass enthusiasts seeking an unparalleled audio experience.

Unmatched Power
The Kraken-MK3 offers the highest SPL in the market from equivalent cubic volume with the output of 4-5 BASSBOSS double 18” subs packed into a cabinet roughly the size of just two. With 10,000 watts RMS of amplification and comprehensive DSP, the amplifier is rated for RMS output using continuous sine wave signal.

Monstrously Beautiful
The subwoofer is capable of almost brutal force and delivers excellent transient response with efficient performance of short horns at the upper end of the subwoofer range. The extended depth is delivered by the large, vented volume, long excursion drivers, and prodigious power.

Innovation Implemented
The MK3 series features all-new amplifiers, with total power increased and power allocated to woofers substantially enhanced. Higher output voltages provide more impact, while universal input voltage compatibility of 90-250V provides more flexibility. Waterproof connections provide more peace-of-mind.

Enhanced DSP
The Kraken-MK3 features an all-new 96kHz DSP, with pushbutton presets doubled from 4 to 8, and up to 100 presets can now be stored in the DSP and loaded via LAN. The suite of processing includes meticulously tuned equalization, all necessary high-pass and low-pass filters, as well as multiple protection systems and limiters to prevent driver overload in as many ways as possible.

ControlBASS Software
ControlBASS software supports an unlimited number of possible BASSBOSS-developed or customized user presets, which integrate seamlessly and coherently with all other BASSBOSS products for effortlessly perfect setups. The latest in DSP programming developments can be added via easy remote updating.

Lose Your Ship!
Get ready to lose yourself in the world of music with the Kraken-MK3, a beast that will captivate your senses with body-quaking, face-melting bass.

Key Features

• Experience pure enjoyment throughout the entire duration!
• Unleash the most intense bass power in the smallest package imaginable.
• The Kraken-MK3 delivers the highest sound pressure level (SPL) available in the market for its size.
• Enjoy the equivalent bass output of 4-5 BASSBOSS double 18” subs, all condensed into a compact cabinet.
• Cutting-edge Quad 21” Self-Powered 6th-order Hybrid Subwoofer.
• Amplification power of 10000 Watts Class D (4 x 2500W) for unparalleled performance.
• Transducer Low Frequency: 4 x 21 in. diameter (540mm) neodymium motor woofer with a 4.5 in. (115mm) voice coil.
• Immerse yourself in the deep, resonating bass produced by this exceptional subwoofer.
• Unmatched power and precision in a compact design.
• Elevate your audio experience with the Kraken-MK3's superior bass capabilities.

Technical Specifications

Loudspeaker Description
Quad 21” Self-Powered 6th-order Hybrid Subwoofer
Frequency Response (±3 dB)
27 - 100 Hz
Maximum Sustained Output
145dB
Max SPL (Peak)*
148dB
Nominal Dispersion (H° x V°)
360 x 360 - Cardioid Mode Available with Multiple Boxes
Amplification
10000 Watts Class D (4 x 2500W)
Processing
Integrated comprehensive DSP. 96kHz sampling rate with 8 pushbutton presets. All presets include high pass filters, low pass filters, phase alignment, equalization and multi-stage limiting. Storage capacity for up to 100 presets
Electrical Connector Amp
Neutrik powerCON True 1 TOP IP65 rated waterproof connectors
Electrical Connector Mains
Standard US 3-pin grounding 120V electrical plug: NEMA 5-15 (Edison)
Voltage Operating Range
100-240V AC, 50-60Hz (Auto-sensing, auto switching universal supply)
Current Draw 120V
18 Volts
Signal Input Connector
XLR-F
Signal Output Connector
XLR-M (direct pass-through only)
Enclosure Type
Vented, short-horn hybrid
Transducer Low Frequency
4 x 21 in. diameter (540mm) neodymium motor woofer with 4.5 in. (115mm) voice coil
Cabinet Construction
CNC machined 18mm Birch plywood with extensive bracing and dado joinery. 8 steel bar handles. 8 x interlocking Nylon sliders/feet.
Exterior Finish
High-pressure, bonded polyurea coating. Rugged, waterproof. Textured black
Grille
Perforated, powder-coated steel
Dimensions (HxWxD)
48 in. x 48 in. x 36 in. (48.5 in. high with feet)
Net Weight
460 lbs
Shipping Weight
550 lbs
What's Included
Loudspeaker, manual, and power cable
Optional Covers
Heavy-duty padded nylon transport covers for 1 cabinet
Optional Dollies
Birch plywood flat cart with 4 locking wheels and recesses to accept the cabinet sliders. Transports 1 or 2 cabinets
True Specifications
Our forward-thinking approach means that we never rest on our laurels. As we continue to innovate and refine our technology, our specifications will evolve. We're committed to constantly pushing the boundaries and raising the bar.
*Peak output is calculated using “industry standard” techniques. These calculation methods create theoretical specifications that are inflated over what can actually be achieved. BASSBOSS real world output specifications are provided as “Maximum Sustained Output” ratings, which reflect actual measured, continuous output levels.
