BASSBOSS SSP215-MK3 5000W Dual 15-Inch Vented Direct-Radiating Powered Subwoofer

BASSBOSS SSP215-MK3: The Perfect Solution for Limited Space and Big Sound
Are you looking for a subwoofer that offers high-quality sound but has a smaller frame? The BASSBOSS SSP215-MK3 may be the answer. With its slim design, this double-15” subwoofer cabinet delivers massive output that rivals double 18” boxes without sacrificing sound quality or low-frequency extension.

Significantly Slender and So Slim So Strong
The SSP215-MK3 has a tight, punchy, and articulate character that is ideal for those who love the robust sound of lower mass 15” cones. This subwoofer is perfect for those who have limited space or constraints in at least one dimension.

Tight Tasty and Make It Rain
With big voice coils, big power amps, and a deep tuning, the SSP215-MK3 delivers significant bass output at and above 35Hz. Its 5000W of amplification and premium-grade DSP provide control and alignment, making it the perfect choice for those who want to make it rain.

MK3 Amp Update and MK3 Enhanced DSP
The MK3 series features all-new amplifiers that deliver higher output voltages for more impact. The DSP programming includes equalization, necessary high-pass and low-pass filters, and multiple protection systems and limiters. With the addition of the all-new 96kHz DSP, the MK3 series offers up to 100 presets that can now be stored and loaded via LAN.

ControlBASS Software
ControlBASS software allows for an unlimited number of BASSBOSS-developed or customized user presets that integrate seamlessly and coherently with all other BASSBOSS products. Remote updating is easy, ensuring that your subwoofer always has the latest in DSP programming developments.

Key Features

• The SSP215-MK3 features the same powerful voice coils and power amps as the SSP218s.
• With its large internal volume and deep tuning, the SSP215-MK3 delivers massive output at and above 35Hz.
• The SSP215-MK3 is designed to replace double 18” boxes without sacrificing output or low-frequency extension.
• This subwoofer is equipped with two 15” neodymium motor woofers with 4” voice coils.
• The Class D amplification of the SSP215-MK3 provides a total power output of 5000 Watts (2 x 2500W).
• The vented direct-radiating design of the SSP215-MK3 ensures optimal sound dispersion.
• The neodymium motor woofers in the SSP215-MK3 deliver exceptional bass performance.
• The large voice coils in the SSP215-MK3 contribute to its powerful and accurate sound reproduction.
• The deep tuning of the SSP215-MK3 allows for extended low-frequency response.
• The SSP215-MK3 is a self-powered subwoofer, eliminating the need for external amplification.

Technical Specifications

Loudspeaker Description
Double 15” Self-Powered Vented Direct-Radiating Subwoofer
Frequency Response (±3 dB)
35 - 100Hz
Maximum Sustained Output
133dB
Max SPL (Peak)*
136dB
Nominal Dispersion (H° x V°)
360 x 360 - Cardioid Mode Available with Multiple Boxes
Amplification
5000 Watts Class D (2 x 2500W)
Processing
Integrated comprehensive DSP. 96kHz sampling rate with 8 pushbutton presets. All presets include high pass filters, low pass filters, phase alignment, equalization and multi-stage limiting. Storage capacity for up to 100 presets
Electrical Connector Amp
Neutrik powerCON True 1 TOP - IP65 rated waterproof connectors
Electrical Connector Mains
Standard US 3-pin grounding 120V electrical plug: NEMA 5-15 (Edison)
Voltage Operating Range
100-240V AC, 50-60Hz (Auto-sensing, auto switching universal supply)
Current Draw 120V
9 Amps (Nominal)
Current Draw 240V
4.5 Amps (Nominal)
Signal Input Connector
XLR-F
Signal Output Connector
XLR-M (direct pass-through only)
Enclosure Type
Direct radiating, vented enclosure, optimally tuned for low frequency response with high sensitivity and high-power handling
Transducer Low Frequency
2 x 15 in. diameter (380mm) neodymium motor woofers with 4 in. (100mm) voice coils
Cabinet Construction
CNC machined 18mm Birch plywood with extensive bracing and dado joinery. 4 integrated handles. 1 x 35mm steel pole socket. 4 rubber feet. 4 interlocking foot pockets. 16 X M10 threaded flypoints
Exterior Finish
High-pressure, bonded polyurea coating. Rugged, waterproof. Textured black
Grille
Perforated, powder-coated steel
Dimensions (HxWxD)
17.25 in. x 48 in. x 29.5 in. (18.5 in. high with feet)
Net Weight
180 lbs
Shipping Weight
220 lbs
What's Included
Loudspeaker, 15' (5m) Power Cable, Manual, Warranty Card
Optional Covers
Heavy-duty padded nylon transport covers for 1 cabinet
Optional Dollies
Birch plywood flat cart with 4 heavy-duty locking casters. 4 pockets to accept the cabinet feet. 7 handles. Transports up to 5 cabinets.
Optional Hardware
M10 Shoulder Eye Bolts, M10 Side-Pull anchors
True Specifications
Our forward-thinking approach means that we never rest on our laurels. As we continue to innovate and refine our technology, our specifications will evolve. We're committed to constantly pushing the boundaries and raising the bar.
*Peak output is calculated using “industry standard” techniques. These calculation methods create theoretical specifications that are inflated over what can actually be achieved. BASSBOSS real world output specifications are provided as “Maximum Sustained Output” ratings, which reflect actual measured, continuous output levels.
